TFT LCD Modules

High-performance TFT LCD modules from 3.5" to 55", engineered for Industrial, Medical, IoT & Smart Home, and Gaming applications. Wide temperature, high brightness, and fully customizable for your project requirements.

Empowering Critical Applications with Advanced Display Technology

Metagrand is a premier global provider of high-performance TFT LCD modules, delivering superior visual solutions that transition your products from traditional displays to vibrant, high-impact digital experiences. Our expertise lies in engineering display modules that excel where others fail—providing unmatched reliability in the most demanding environments.

Key Features

Standard & Industrial TFTs
3.5"~55", customizable & integrated solutions

Ruggedized Displays
Aviation, Marine, Military

High-Brightness & Sunlight Readable
Up to 1000+ nits

All-Weather Performance
-30°C to +80°C

IPS Technology
Wide viewing angles & consistent color

Advanced Connectivity
HDMI, LVDS, MIPI, Serial/Parallel

Key Applications

Industrial Equipment

Medical Instruments

Home Appliances & Smart Home

Smart Energy & POS Systems

Vending Machines & EV Charging Stations

Automotive & Avionics Displays

Marine & Military Applications

TFT LCD Module Product List

Size	Part Number	Resolution	Type	Brightness	Interface	Operating Temp. (°C)
1.54"	LA0154XTSN75AAA01	240×240	IPS	750	SPI	-20~+70
2.0"	LA0200XTSC50CAA01	320×240	IPS	500	SPI	-20~+70
2.1"	LA0210XTMCA0DDA01	480×480	IPS	1000	MIPI	-20~+70
3.5"	LA0350XTXN35CAA01	320×240	TN	350	RGB+SPI	-20~+70
3.5"	LA0350XTTN75CDB01	320×480	IPS	750	RGB	-10~+60
3.71"	LA0371XTMN35AJA01	240×960	IPS	350	MIPI	-20~+70
4.0"	LA0400BTTO35DDA01	480×480	IPS	350	TTL 24bits	-20~+70
4.0"	LA0400BTMCA1DIB01	480×800	IPS	1100	MIPI 2Lane	-30~+85
4.3"	LA0430XTTN45DBA01	480×272	IPS	450	TTL 24bits	-20~+70
4.3"	LA0430XTXN40DIB01	480×800	IPS	400	RGB+SPI	-20~+60
4.3"	LA0430XTLN301DC01	800×480	IPS	300	LVDS	-10~+60
4.3"	LA0430XTLNA0QLD01	1920×1080	IPS	1000	LVDS	-20~+70
5.0"	LA0500XTTN50IDA01	800×480	IPS	500	TTL 24bits	-20~+70
5.0"	LA0500XTMRAOGNB01	720×1280	IPS	1000	MIPI	-20~+70
5.5"	LA0550XTMN30LQA01	1080×1920	IPS	300	MIPI	-20~+60
5.7"	LA0570BTTN55FDA01	640×480	IPS	550	TTL 18bits	-20~+70
5.98"	LA0598ATMN40PSA01	1440×2560	IPS	400	MIPI 8 Lane	-20~+70
6.8"	LA0680BTTC801DA01	800×480	IPS	800	TTL 24bits	-30~+85
7.0"	LA0700BTTN351DA01	800×480	TN	350	TTL 24bits	-20~+60
7.0"	LA0700XTTN48IDB01	800×480	IPS	480	TTL 24bits	-30~+85
7.0"	LA0700XTTN701DC01	800×480	TN	700	TTL 24bits	-20~+70
7.0"	LA0700XTTN501DD01	800×480	TN	500	TTL 24bits	-20~+70
7.0"	LA0700BTLCADKEE01	1024×600	IPS	1000	LVDS	-20~+70
7.0"	LA0700BTTCAOKEF01	1024×600	IPS	1000	TTL	-20~+70
7.0"	LA0700BTLCAOKEG01	1024×600	TN	1000	LVDS	-20~+70
7.0"	LA0700XTMNB0MQH01	1200×1920	IPS	2000	MIPI	-20~+70
7.0"	LA0700XTMN45INI01	800×1280	IPS	450	MIPI	-20~+60
7.0"	LA0700XTLN45INJ01	800×1280	IPS	450	MIPI-LVDS	-20~+60
8.0"	LA0800XTTN451EA01	800×600	TN	450	TTL 24bits	-20~+70
8.0"	LA0800XTLNAOKEB01	1024×600	TN	1000	LVDS	-20~+70
8.0"	LA0800XTMN25INC01	800×1280	IPS	250	MIPI	-10~+50
8.8"	LA0880HTMN80QDA01	1920×480	IPS	800	MIPI 4 Lane	-20~+70
9.0"	LA0900XTLN45KEA01	1024×600	TN	450	LVDS	-20~+60
10.1"	LA1010XTTN30KEA01	1024×600	IPS	300	TTL 24bits	-10~+50
10.1"	LA1010XTLNAOKEB01	1024×600	IPS	1000	LVDS	-20~+70
10.1"	LA1010XTLN50KEC01	1024×600	TN	500	LVDS	-20~+70
10.1"	LA1010HTLNAONID01	1280×800	IPS	1000	LVDS	-30~+80
10.1"	LA1010HTLCAONIE01	1280×800	IPS	1000	LVDS	-30~+80
10.1"	LA1010XTLN30INF01	800×1280	IPS	300	LVDS	-20~+50
10.1"	LA1010BTMNA0QMG01	1920×1200	IPS	1000	MIPI	-10~+60
10.1"	LA1010BTLNA0QMH01	1920×1200	IPS	1000	LVDS	-10~+60
11.6"	LA1160XTTN45HDA01	1366×768	IPS	450	LVDS	-20~+70
12.1"	LA1210XTTN30HDA01	1280×800	IPS	300	LVDS	-20~+70
12.1"	LA1210XTMN50HDB01	1920×1200	IPS	500	MIPI	-20~+70
13.3"	LA1330XTTN60HDA01	1920×1080	IPS	600	LVDS	-20~+70
15.6"	LA1560XTTN60HDA01	1920×1080	IPS	600	LVDS	-20~+70
17.0"	LA1700XTTN60HDA01	1920×1080	IPS	600	LVDS	-20~+70

Commitment to Quality

Whether you require a portrait or landscape orientation, Metagrand provides the technical support and manufacturing excellence needed to bring your vision to life. We are committed to driving industry innovation through reliability, precision, and customer-centric design.
